Our profiled Q STRIP is suitable for rooms where a linear and square aesthetic geometry is required, marked by the play of shadows created by the joint and the height with the ceiling.
It has the particularity of being multi-modular on the carrier.
Technical specifications
| European regulation: | CE - EN 13964 |
| Durability: | Class B |
| Fire resistance: | A1 |
| Acoustic absorption: | EN ISO 354 |
| Standard colour: | Silver • White • AISI • Post-painted |
| Finishing: | Smooth • Perforated |
| Standard material: | Aluminium (3000H46/1050AH) Galvanized steel (DX51DZ) |
| Standard thickness: | Aluminium 0,5 - 0,6 - 0,8 mm Steel 0,4 - 0,5 - 0,6 mm |
| Standard dimensions: | Q35 - 35x35 mm Q85 - 85x15 mm Q135 - 135x15 mm Q185 - 185x15 mm Q30 - 30x38 mm Q40 - 40x40 mm Q90 - 90x30 mm |
Finish
Q35/85/135/185 Strip
Q30 Strip
Q40 Strip
Q90 Strip
