T-Structures for modular false ceilings are still the most popular product in our range. Over the years, we have developed various innovative, earthquake-resistant and at the same time demountable suspension systems.
The quality of our profiles is attested by the full marking according to Regulation (EU) 305/2011, which establishes harmonized conditions for the marketing of construction products, and by the CE marking on the product according to European standard EN 13964 (mechanical resistance to bending of ceiling products). Telematically all products are accompanied by the PDO (Declaration of Performance), which indicates the product characteristics according to Annex ZA, such as reaction to fire (EN 13501-1), release of hazardous substances, thickness, load, yield strength, durability and flexural class. The CE mark and the information is applied to the product in question.
The product has a REI120 fire resistance certificate (13501-2) in combination with rock wool or fibre panels with equivalent characteristics concrete floor of clay. Thanks to the use of our LEED mapping obtained in cooperation with TUV Italy, the products contribute to meeting the credits of LEED certification by analysing all the aspects for which they contribute to the sustainability of buildings in terms of their recycled material content as well as their energy contribution which they make.
Freccia
Overlapping profile with “riportato” hook
Freccia for T24 and T15 is the point of reference for applicators. With Freccia it is possible to produce multiple modules based on metric (mm) and imperial (inch) systems. The strong point is that the profile can be assembled and removed without any damage to the “riportato” hook and made of stainless steel. For the production of the T-Structure, standard version uses hot-dip Galvanized steel according to EN 10346. If other types of steel are used, the substructures are produced from materials in accordance with EN 10152, EN 10169-1. The tolerances and thicknesses checked in accordance with the requirements of EN 10143 (for EN 10346 and EN 10169) and EN 10131 (for EN 10152).
Technical specifications
| Structure material: Coating material: Hook material: | Galvanized steel DX51D+Z100 MAC Zinc plated steel DX51D+Z100 MAC Stainless steel |
| Connection between profiles: | Bearing: arrow pressed hook Secondary: clip hook |
| Colour of coating: | Pre-painted White DONN-WHITE Silver / Black Mirror aluminium |
| Weight of structure: | ca. 1 Kg/m² |
| Medium load capacity: | 52,3 N |
| Fire reaction: | Class A1 |
| Organic coating: | Polyester paint 25μm |
| Breaking load: | 281 N/mm² |
| Durability: | Class B |
| Flexion class: | 1 (UNO) T24 2 (DUE) T15 |
| Packaging: | Cardboard box with plastic strapping |
| Exposure class: | A |
X Seismic
Overlapping profile with “riportato” anti-seismic hook
X Seismic for T24 and T15, they are profiles that can be used to create multiple modules based on both metric (mm) and imperial (inch) systems. The main feature of the profile is the stainless steel hook, which permits simple and intuitive assembly, providing a solid lock. For the production of the T-Structure, hot-dip galvanised steel in accordance with EN 10346 is used in the standard version; if other types of steel are employed, the substructures are produced with materials in accordance with EN 10152, EN 10169-1. The tolerances and thicknesses checked in accordance with the requirements of EN 10143 (for EN 10346 and EN 10169) and EN 10131 (for EN 10152).
Technical specifications
| Structure material: Coating material: Hook material: | Galvanized steel DX51D+Z100 MAC Zinc plated steel DX51D+Z100 MAC Stainless steel |
| Connection between profiles: | Bearing: profile "ricavato" hook Secondary:"riportato" hook |
| Colour of coating: | Pre-painted White DONN-WHITE Silver / Black Mirror aluminium |
| Weight of structure: | ca. 1 Kg/m² |
| Medium load capacity: | 52,3 N |
| Fire reaction: | Class A1 |
| Organic coating: | Polyester paint 25μm |
| Breaking load: | 281 N/mm² |
| Durability: | Class B |
| Flexion class: | 1 (UNO) T24 2 (DUE) T15 |
| Packaging: | Cardboard box with plastic strapping |
| Exposure class: | A |
Classic Line
Overlapping ping profile with “ricavato” hook
Classic Line for T24 and T15, they are profiles with which it is possible to create multiple modules based on the metric (mm) and imperial (inch) system. The most important feature of the profile is its classic line with a “ricavato” hook, which guarantees solidity and strength. For the production of the T-Structure, hot-dip galvanized steel in accordance with EN 10346 is used in the standard version; if other types of steel are employed, the substructures are produced with materials in accordance with EN 10152, EN 10169-1. The tolerances and thicknesses checked in accordance with the requirements of EN 10143 (for EN 10346 and EN 10169) and EN 10131 (for EN 10152).
Technical specifications
| Structure material: Coating material: | Galvanized steel DX51D+Z100 MAC Alluminio (Lega 3000H64) Zinc plated steel DX51D+Z100 MAC Alluminio preverniciato (Lega 3000H64) |
| Connection between profiles: | Bearing: profile "ricavato" hook Secondary: clip hook |
| Colour of coating: | Pre-painted White DONN-WHITE Silver / Black Mirror aluminium |
| Weight of structure: | ca. 1 Kg/m² |
| Medium load capacity: | 52,3 N |
| Fire reaction: | Class A1 |
| Organic coating: | Polyester paint 25μm |
| Breaking load: | 281 N/mm² |
| Durability: | Class B |
| Flexion class: | 1 (UNO) T24 2 (DUE) T15 |
| Packaging: | Cardboard box with plastic strapping |
| Exposure class: | A |
Baionetta
Jointed profile with “ricavato” hook
Baionetta for T24 is the profile with which it is possible to create multiple modules based on both the Metric (mm) and Imperial (inch) system. The feature that most distinguishes the profile is its line, with a “ricavato” hook and reinforced boss ensuring solidity and strength. For the production of the T-Structure, hot-dip galvanized steel in accordance with EN 10346 is used in the standard version; if other types of steel are employed, the substructures are produced with materials in accordance with EN 10152, EN 10169-1. Tolerances and thicknesses checked according to the requirements of EN 10143 (for EN 10346 and EN 10169) and EN 10131 (for EN 10152).
Technical specifications
| Structure material: Coating material: | Galvanized steel DX51D+Z100 MAC Pre-painted steel DX51D+Z100 MAC |
| Connection between profiles: | Bearing: "ricavato" hook Secondary: Baionetta "ricavato" hook |
| Colour of coating: | Pre-painted White DONN-WHITE Silver / Black Mirror aluminium |
| Weight of structure: | ca. 1 Kg/m² |
| Medium load capacity: | 52,3 N |
| Fire reaction: | Class A1 |
| Organic coating: | Polyester paint 25μm |
| Breaking load: | 281 N/mm² |
| Durability: | Class B |
| Flexion class: | 1 (UNO) T24 2 (DUE) T15 |
| Packaging: | Cardboard box with plastic strapping |
| Exposure class: | A |
